Key Features



Each slat is filled with a tough CFC free insulating foam helping to keep your garage cooler in summer, warmer in winter. Guides are brush lined for draught proofing and at the bottom there is a bubble seal to help prevent ingress of water and dust.

Head Room

The large 77mm slat featured above, when rolled up takes up only 355mm of head room, whereas the smaller slat, when rolled up, uses only 260mm of head room.

See technical help

Head Room



Single phase, tubular, fitted within axle, left or right; we have tried and tested over 20 years, VERY RELIABLE - Normal power supply. Uses only small amounts of power.

Heavy Duty Steel Endplates

Very sturdy, don’t move as door lifts and closes. Greater safety and security with maximum anchorage for the axle and coil.

Heavy Duty Steel Endplates

Heavy duty steel endplates

Heavy Duty Axle

This is a special fluted design, 102mm in diameter which prevents the axle from sagging. The specially shaped axle collars allow the door to roll up symmetrically.

All the moving points in the door curtain happily roll around the rigid axle providing quiet operation and long life.


Double wall extruded aluminium guides are 60mm, 75mm or 90mm wide depending on the width of your door. Can be face fixed to the inside of your garage or reveal fitted between the garage opening.




The door is made from interlocking 77mm slats which are double skin insulated aluminium and powder coated.


A special braid holds the roller door together at each end, preventing sideways slat travel. This means that a potential thief cannot break in through attempting to slide out slats.

This braid is fixed to both ends on the reverse of the door and the guides are brush lined. Not only do these two very important features help to prevent slats becoming scratched as they roll up and down, they also ensure smoother, quieter operation. The braid also separates one surface of the slat from another, eliminating thousands of hairline abrasions. The surface of our doors therefore stays in pristine condition.

View attack demo



Space saving

Space Saving

By eliminating the need for a subframe, drive through width and height is maximised. Rising and falling vertically, no “up and over” space is taken up in the drive and the ceiling space inside the garage is clear.


If there is any inherent fault with our product, the offending part or parts will be replaced free of charge. We offer a fully comprehensive 5-year guarantee. Woodgrain finishes are guaranteed for 10 years.

5 year guarantee


If part of the slatted door is damaged we can supply replacement slats, not the whole curtain, therefore keeping future cost down.

Maintenance Free

Our door is virtually maintenance free. No painting or greasing up is required. Regular washing with mild detergent solution will keep it in pristine condition.
